Voltage drop is an important factor in the design & analysis of the electrical systems, especially in DC circuits.

It refers to the voltage drop that happens when electric current travels via the resistive components of a conductor.

This reduction can have an important effect on the functioning of electrical devices, particularly when operating over long distances (or) with high current.

Understanding Voltage Drops in DC Circuits

In an ideal condition, electrical current must reach the load without any voltage drop.

However, in fact, all conductors provide some resistance to the flow of electricity.

This resistance causes some electrical energy (voltage) to be lost throughout the length of the wire, leading to a voltage drop.

Key Parameters affecting Voltage Drop

Several factors affect the range of voltage drop in a conductor:

Wire Resistivity (ρ)

Wire Resistivity (ρ) is a material attribute that reflects how strongly it opposes current flow.

Ex: Copper has a lower resistivity than steel, making it a superior conductor.

Length of the Conductor (L)

Longer cables have more resistance and thus a higher voltage drop.

Current (I)

The voltage drop is proportional to the amount of current flowing via the conductor.

Cross-Sectional Area of Conductor (A)

Thicker wires have lower resistance and thus lower voltage drops.

Number of Conductors in Parallel (n)

Connecting many conductors in parallel lowers overall resistance.

Formula for DC Voltage Drop

The voltage drop in a DC circuit with a complete loop (go & return path) can be estimated using the following formula:

V_Drop ​= (2 x I x L x R) / (A×n)

Where

V_Drop​ – Voltage drop (V) (Volts)

I – Current (A) (Amperes)

L – One-way length of Wire (m) (meters)

R – Resistivity of Wire Material (Ω-m)

A – Cross-Sectional Area of Wire (mm²)

n – Number of Conductors in Parallel

Voltage Drop Percentage (%) Calculation

To determine if the voltage drop is within permissible limits, represent it as a percentage of the starting voltage:

Voltage Drop (%) = (V_Drop / V_Intial) x 100

Where

V_Drop – Calculated Voltage Drop (V)

V_Intial – Source Voltage (V)

Most common applications require a voltage drop of no more than 3% of source voltage. Beyond this limitation, it may result in:

• Dim (or) flickering lights.
• Overheating of the electrical equipment
• Inefficient operation of motors & other loads.

Output Voltage Calculation

Once the voltage drop is determined, the output voltage at Load end can be computed as:

V_Output = V_Intial – V_Drop

​Where

V – Voltage available at load (V) (Volts).

Recommendations to reduce Voltage Drop

1. To reduce resistance, use materials with high conductivity, such as copper or aluminum.
2. To reduce resistive losses, use cables with a higher cross sectional area.
3. By optimizing the layout design, you may keep the wire length to a minimum.
4. Reduce the load current if possible, or distribute it across many conductors.
5. Consider utilizing parallel conductors to reduce total resistance.

Voltage drop in DC circuits is unavoidable due to resistance of conductive materials.

To ensure that electrical equipment operates efficiently and safely, voltage drop must be calculated and controlled correctly.

Engineers can reduce the negative effects of voltage drop on system performance by adopting proper

• Wire sizing,
• Material selection, and
• Installation techniques.
